FPL6280 - Sauna Cube 328x656 with lounge room

FPL6280 - Sauna Cube 328x656 with lounge room

Sauna Cube 3.28m x 6.56m with lounge room

PRODUCT DESCRIPTION

The Sauna Cube 3.28m x 6.56m with lounge room is a four room insulated Garden Cube made from 2x connected garden cube frames measuring 3 x 4m and 3 x 2m, With wooden floor, lounge room, shower room, changing room and sauna room, with inside sauna door and sauna benches. Frames are made from glue laminated spruce beams: bottom frame (100 x 140 mm), columns (140 x 140mm), top frame (140 x 240mm) and withstands 442 kg/m2 roof load.


SPECIFICATION:

  • External dimension: 3286mm x 4286mm + 3286mm x 2286mm
  • Total height: 2780mm
  • Wall height: 2200mm
  • Exterior Cladding: 18mm​
  • Interior Cladding: 12mm​
  • Door size: 3000mm x 2200mm
  • Wall thickness: 75mm
  • Floor thickness: 28mm
  • Insulation: 50mm stone wool
  • Roof:  The roof panels are built with double rafters construction and covered with 18 x 145mm finishing boards
  • Roof covering: EPDM
  • Doors: 3 rail, aluminium Alutech door system with 4mm tempered glass
  • Walls: FSC-certified spruce walls: 1000 x 2200mm. Standard full panel wall: Wall frame 75 x 45mm, panel covered with inside 96 x 12mm and outside 145 x 18mm horizontal spruce cladding boards; Insulated full panel wall: Wall frame 75 x 45mm
  • Wooden shower door: 990 x 2195mm
  • Sauna glass door: 698 x 1855mm
  • Interior tinted glass door: 620 x1800mm
  • 2x sauna benches: 500mm (W) x 2136mm (L)
  • Heat-resistant plates for the heater/stove

Code: GSC3X6

These are modular cabins which can be modified within certain criteria, please enquire for more details.
